Product Description:
Fiber optic tail is a semi-jumper-like joint used to connect the optical fiber and the optical fiber coupler. It consists of a connector and a section of optical fiber.
Product Performance:
Connector Type SC/UPC Cable Diameter 0.9mm Cable Length 2m Sheath Material PVC Insertion Loss (dB) ≤0.3dB Return Loss (dB) ≥50dB Fiber Standard G.652D Color 12 different colors Repeatedly (1000 times) ≤0.3dB Interchangeability ≤0.3dB Durability (dB) ＜0.1dB (500 Matings, per EIA-455-21A)
Pictures:
Applicable Environment:
Working temperature: – 40°C to + 80°C Working humidity: <85%(+40°C) Working Pressure: 70-106 kPa Storage temperature: – 40°C to + 85°C Storage humidity: <85%(+40°C)
